Features:
- Singlemode 9/125 OS2
- Plenum Rated Yellow Indoor/Outdoor rated jacket
Applications
- Outdoors in Duct
- Indoors in the Plenum Space
- Tray Installations
Cable Construction Details
- Tight Buffered Fiber Dimension: 900μm, Nominal
- Tight Buffer Color Code: As per TIA/EIA-598 standard or per customer requirement
- Cable Strength: Water swellable aramid yarns are pulled in with tight buffered fibers under the outer jacket
- Overall Sheath: UV Resistant Remguard Plenum Rated Polymer
Applicable Documents
- TIA/EIA FOTP Standards 455
- Color Coding of Fiber Optic Cables TIA/EIA-598
- UL 910
- GR-409-CORE
- Compliant with ANSI/TIA-568-C.3 standard
- Part #11E3-Y012NH
- Warranty:Lifetime
- UPC Number:846568051494
- End 1:Bare end
- End 2:Bare end
- Length:1000 feet
- Color:Yellow
- Weight:35.00 lbs
Helpful Downloads
- PDF Spec Sheet
